描述
| ITEM | DESCRIPTION |
| RATED VOLTAGE | 12 VDC |
| OPERATING VOLTAGE | 7.0～15 VDC |
| STARTING VOLTAGE | 7.0 VDC |
| POWER ON PEAK CURRENT(VP+) | 2A |
| FAN BLADE LOCK CURRENT(MAX.) | 2A |
| POWER ON FAN SPEED DELAY TIME | MAX.6 SECONDS(FULL DUTY AT RATED VOLTAGE) |
| TIMES OF THE PWM SIGNAL CHANGE | MAX.20 SECONDS(ANY DUTY CHANGE TO RATED SPEED) |
| RATED CURRENT(AVG.) | 0.6/MAX.0.72 A |
| RATED POWER(AVG.) | 7.2/MAX.8.64 W |
| SAFETY POWER CONSUMPTION | 7.2W |
| RATED SPEED | 18000 RPM±10%IN FREE AIR AT RATED VOLTAGE |
|
AIRFLOW AT ZERO STATIC PRESSURE |
NOMINAL 24.35 CFM/MIN 21.6 CFM
NOMINAL 0.70 M³/MIN/MIN 0.61M³/MIN |
|
STATIC PRESSURE AT ZERO AIRFLOW |
NOMINAL 2.12 inch-H₂O/MIN 1.38inch-H₂O NOMINAL 53.81 mm-H₂O/MIN 35.05mm-H₂O |
| ACOUSTICAL NOISE(AVG.) | NOMINAL 55.7 dB(A)/MAX 60.3 dB(A) |
| INSULATION TYPE | UL CLASS A |
| INSULATION RESISTANCE | 10M OHM MIN.AT 500 VDC BETWEEN FRAME AND(+) TERMINAL |
|
DIELECTRIC STRENGTH |
5mA MAX.AT AC 500 VAC 50/60 Hz ONE MINUTE BETWEEN FRAME AND(+)TERMINAL |
| LIFE EXPECTANCY | 70,000 HOURS AT 40℃WITH 15~65%RH |
| DIRECTION OF ROTATION | COUNTER-CLOCKWISE FROM BLADE SIDE |
| INGRESS PROTECTION | IP21 |
